⚙️ Core Specs

• GPU: NVIDIA GeForce RTX 5060 Ti (Blackwell GB206)

• CUDA Cores: 4608

• Memory: 16GB GDDR7, 128-bit bus, blazing-fast 28 Gbps

• Interface: PCIe Gen 5 x8

• Boost Clock: Up to 2602 MHz (Extreme Performance mode via MSI Center)

• Bandwidth: 448 GB/s

🌀 Cooling & Design

• VENTUS 2X Cooling:

  • Dual TORX Fan 4.0 with alternate spinning

  • Precision-machined heatpipes and aluminum heatsink

  • Compact dual-slot design (227 × 126 × 41 mm)

• Power: 180W TDP, single 8-pin connector

• Recommended PSU: 600W

🔌 Display & Connectivity

• Outputs:

  • 3× DisplayPort 2.1b

  • 1× HDMI 2.1b (supports up to 8K @ 120Hz or 4K @ 480Hz with DSC)

• Max Resolution: 7680 × 4320

• Multi-display Support: Up to 4 monitors

🧠 Feature Set

• Ray Tracing: 4th Gen RT cores

• AI Acceleration: 5th Gen Tensor cores with DLSS 4

• Encoding/Decoding: 9th Gen NVENC, 6th Gen NVDEC

• API Support: DirectX 12 Ultimate, Vulkan 1.4, OpenGL 4.6
