GPU and Architecture

• GPU: AMD Radeon RX 9060 XT

• Architecture: AMD RDNA 4

• Stream Processors: 2048

  Compute Units: 32 (with 3rd Gen RT and 2nd Gen AI Accelerators)

Clock Speeds

• Boost Clock: Up to 3320 MHz

• Game Clock: Up to 2780 MHz

Memory

• Memory Size: 16 GB GDDR6



• Memory Bus: 128-bit

• Memory Speed: 20 Gbps Effective

• Infinity Cache: 32 MB

Power and Cooling

• Typical Board Power (TDP): 182W

• Power Connector: 1x 8-pin

  Recommended PSU: Minimum 450W

• Cooling: SAPPHIRE's Tri-X Cooling Technology (Triple Axial Fan)

Display Outputs

• Outputs: 2x HDMI 2.1b, 1x DisplayPort 2.1a

• Max Resolution: 7680x4320
